| Brand | SAPPHIRE |
|---|---|
| Series | PULSE |
| Model | 11350-04-20G |
| Part Number | 11350-04-20G |
| Interface | PCI Express 5.0 x16 |
|---|
| Chipset Manufacturer | AMD |
|---|---|
| GPU Series | AMD Radeon RX 9000 Series |
| GPU | Radeon RX 9060 XT |
| Architecture | RDNA 4 |
| Game Clock | 2700 MHz |
| Boost Clock | 3290 MHz |
| Stream Processors | 2048 Stream Processors |
| Effective Memory Clock | 20000 MHz (20 Gbps) |
|---|---|
| Memory Size | 8GB |
| Memory Interface | 128-Bit |
| Memory Type | GDDR6 |
| DirectX | DirectX 12 Ultimate |
|---|
| Multi-Monitor Support | 3 |
|---|---|
| HDMI | 2 x HDMI |
| DisplayPort | 1x DisplayPort™ 2.1a |
| Color | Black |
|---|---|
| Max Resolution | 7680 x 4320 |
| Cooler | Double Fans |
| Thermal Design Power | 170W |
| Recommended PSU Wattage | 450W |
| Power Connector | 8-Pin |
| HDCP Ready | Yes |
| Form Factor | ATX |
|---|---|
| Max GPU Length | 244 mm |
| Card Dimensions (L x H) | 244 x 124 x 46.1 mm |
| Slot Width | 2.3 Slots |
